車の計器板型
Created with Pixso.

Dial Gauge Car Instrument Panel Mould CNC Dilling Automobile Display Stand

Dial Gauge Car Instrument Panel Mould CNC Dilling Automobile Display Stand

ブランド名: EMT
MOQ: 交渉可能
価格: negotiable
支払条件: T/T、ウェスタン・ユニオン
供給能力: 50000PCS /Month
詳細情報
起源の場所:
中国
証明:
TS16949、IOS9001
生産設備のモデル:
800Tマグネシウムの合金の半固体射出成形機械
材料:
マグネシウムの合金
表面処理:
、酸化物電気めっきする、粉のコーティング陽極酸化
次元:
必要な顧客
処理:
CNCの回転、製粉の部品、Dilling、自動旋盤、叩くこと、薮で囲むこと、表面処理、等。
試験装置:
CMM/用具の顕微鏡/複数の接合箇所の腕/自動高さのゲージ/手動高さのゲージ/ダイヤルのゲージ/荒さの測定
パッケージの詳細:
顧客の必要性に従って
供給の能力:
50000PCS /Month
ハイライト:

Dilling Car Instrument Panel Mould

,

Dial gauge Car Instrument Panel Mould

,

CNC Automobile display stand

製品説明

Dial Gauge Car Instrument Panel Mould CNC Dilling Automobile Display Stand

Specification:

Product name holder
Specification Auto parts
Unit weight 0.3KG


Product Advantage:

The manufacturing material requirements of instrument panel base: good deformation performance, light weight, high dimensional accuracy, simplified parts structure, etc. Magnesium alloy can meet these requirements. Audi V8 in the 1980s is an integral die-cast with a length of 1440mm, wall thickness of 3.5mm and a mass of about 4.3kg. With a mass reduction of about 65% compared to steel, the structure is greatly simplified, integrating a base that used to require 30 to 60 parts into a single piece. The monolithic base provides support structures for the "A" struts, HVAC(heating, ventilation, and air conditioning) controllers, airbag boxes, air-conditioner lines, driving rods, brake, clutch pedals, and other components, recently added beams and speedometers, radios, and glove box brackets.

Conventional models of steering system support and guide cylinder is given priority to with sheet metal parts and round steel, the steering column is tight on the body frame by bolts, but because most car body stents are welding sheet metal stamping parts, will produce certain welding deformation, resulting in the steering column installed on the body frame, sheet metal stents will along with the deformation of body frame occur deformation, The whole steering pipe string is deformed, and some parts deviate from the design position, so that the slip force is too large, and the phenomenon of adjusting hairpin and abnormal sound is generated. Due to the rigidity of the magnesium alloy is great, not after installation with deformation and deformation for the body, so as to avoid the above phenomenon, a comprehensive guarantee steering system in the process of the vehicle collision, the steering column can be done according to the design of the stroke and the energy absorption curve crumple the whole dynamic process, provide the safety of the vehicle collision, The stiffness and frequency of the steering system are greatly improved, and the lightweight design is achieved, which reduces the mass by more than 5% compared with the conventional model originals.



Dial Gauge Car Instrument Panel Mould CNC Dilling Automobile Display Stand 0

Dial Gauge Car Instrument Panel Mould CNC Dilling Automobile Display Stand 1

Dial Gauge Car Instrument Panel Mould CNC Dilling Automobile Display Stand 2

Advantage:

Dial Gauge Car Instrument Panel Mould CNC Dilling Automobile Display Stand 3



FAQ:

1. Q:Are you a factory or a trading company?

A:We are a factory which has been focus on Magnesium alloy deep processing lightweight field & semi-solid injection molding of Magnesium alloy for more than 16+ years.

2. Q: Is there quality control on all production lines?

A: Yes, all production lines have adequate quality control.

3. Q: Has the company established and implemented a standard procedure for purchasing contract review and approval?

A: Yes, with written standard procedures.

4. Q: Is there a procedure to conduct random product inspections after final packaging?

A: Yes, with clear standard and written inspection records.

5. Q: How can I get a quotation?

A: Please kindly send us following information 1) Product drawings by STEP/STP/PRT/PDF/IGS format etc. 2) Material, size and surface treatment request. 3) Required quantity. Normally,the quote will be offer in 1-6 hours. :)

6. Q: What is your payment terms?

A: T/T, Western Union, etc.
